ALLEVIATE [Phase 4 Design]
Shown are the current designs of the ALLEVIATE1 back muscle recovery device. The overall design uses three mechanical systems to provide an effective deep tissue massage. These systems consist of Air Compression, 360° Ball Rollers, and a Zero Gravity Recliner. The systems work together to provide an innovative and cutting edge muscle recovery device design unlike anything on the current market.
​
Seen on the figure to the right is the current ALLEVIATE1 prototype design. Shown below are the assembly models and components of the massage roller mechanism.
​
The ALLEVIATE1 massage rollers utilizes smooth rolling in 360° allowing the mechanism to move horizontally and vertically with little to no drag. The air compression vest puts the necessary pressure on the user for the rollers to apply an effective deep tissue massage on the individual.
Massage Roller System
ALLEVIATE1 Back View
ALLEVIATE1 Front View
ALLEVIATE [Phase 3 Design]
Shown is the ALLEVIATE1 Phase 3 design back muscle recovery device. This design was created as a base for the Phase 4 design to push PALMARTech in the right direction of what our product would look like. Above is the PALMARTech ALLEVIATE1 Phase 4 design, a much more refined and thought out prototype design.
Massage Roller
Ball Nut Housing
ALLEVIATE1 Back View
Massage Mechanism Assembly
